Descripción
Marca: TP-Link
Modelo: TL-SG1005LP
Características de Hardware: – Interfaz: 8 × 100/1000/2500 Mbps RJ45 PoE+ Ports 2 × 10G SFP+ Slots – Cantidad de ventiladores: Fanless – Bloqueo de Seguridad Física – Fuente de Alimentación: Adaptador de Corriente 53.5VDC/3.37A – Puertos PoE (RJ45) Estándar: compatible con 802.3at/af Puertos PoE+: 8 puertos Presupuesto de energía PoE: 160 W – Montaje: Sobremesa/Pared – Consumo de Potencia Máximo: 180,1 W (110V/60Hz) (con 160 W PD conectado) – Disipación máxima de calor: 614,58 BTU/hr (110 V/60 Hz) (con 160 W PD conectado) – Dimensiones: 226 × 131 × 35 milímetros
Rendimiento: – Capacidad de Conmutación: 80 Gbps – Tasa de Reenvío de Paquetes: 59.52 Mpps – Tabla de Direcciones MAC: 16 K – Memoria del Buffer de Paquete: 12 Mbit – Jumbo Frame: 9 KB
Características de Software: Calidad de Servicio – 802.1p CoS/DSCP priority – 8 priority queues – Priority Schedule Mode SP (Strict Priority) WRR (Weighted Round Robin) – Queue Weight Config – Bandwidth Control Port/Flow based Rating Limit – Smoother Performance – Storm Control Multiple Control Modes(kbps/ratio) Broadcast/Multicast/Unknown-Unicast Control Características L2 y L2+ – 32 IP Interfaces: Support IPv4/IPv6 Interface – Static Routing: 32 IPv4/IPv6 Static Routes – DHCP Server – DHCP Relay DHCP Interface Relay DHCP VLAN Relay – DHCP L2 Relay – Static ARP – Proxy ARP – Gratuitous ARP – Link Aggregation – Spanning Tree Protocol – Loopback Detection – 802.3x Flow Control – Mirroring – Device Link Detect Protocol (DLDP) – 802.1ab LLDP/ LLDP-MED Multicast L2 – 511 IPv4, IPv6 shared multicast groups – IGMP Snooping – Multicast VLAN Registration (MVR) – Multicast Filtering – Limited IP Multicast (256 profiles and 16 entries per profile) Características Avanzadas – Automatic Device Discovery – Batch Configuration – Batch Firmware Upgrading – Intelligent Network Monitoring – Abnormal Event Warnings – Unified Configuration – Reboot Schedule VLAN – VLAN Group Max 4K VLAN Groups – 802.1Q Tagged VLAN – MAC VLAN: 12 Entries – Protocol VLAN – GVRP – Voice VLAN Lista de Control de Acceso – Support up to 230 entries – Time-based ACL – MAC ACL – IP ACL – IPv6 ACL – Combined ACL – Rule Operation: Permit/Deny – Policy Action Mirroring Redirect Rate Limit QoS Remark – ACL Rules Binding Port Binding VLAN Binding Seguridad – IP-MAC-Port Binding – AAA – 802.1X Port based authentication MAC (Host) based authentication Authentication Method includes PAP/EAP-MD5 MAB Guest VLAN Support Radius authentication and accountability – IP/IPv6-MAC Binding 512 Binding Entries DHCP Snooping DHCPv6 Snooping ARP Inspection ND Detection ND Snooping – IP Source Guard 253 Entries Source IP+Source MAC – IPv6 Source Guard 183 Entries Source IPv6 Address+Source MAC – DoS Defend – DHCP Filter – Static/Dynamic/Permanent Port Security Up to 64 MAC addresses per port – Broadcast/Multicast/Unicast Storm Control – Port Isolation – Secure web management through HTTPS with SSLv3/TLS 1.2 – Secure Command Line Interface (CLI) management with SSHv1/SSHv2 – IP/Port/MAC based access control IPv6 – IPv6 Static Routing and ACL – IPv6 Dual IPv4/IPv6 – IPv6 Interface – Multicast Listener Discovery (MLD) Snooping – IPv6 neighbor discovery (ND) – Path maximum transmission unit (MTU) discovery – Internet Control Message Protocol (ICMP) version 6 – TCPv6/UDPv6 – IPv6 applications DHCPv6 Client Ping6 Tracert6 Telnet(v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP MIBs – MIB II (RFC1213) – Interface MIB (RFC2233) – Ethernet Interface MIB (RFC1643) – Bridge MIB (RFC1493) – P/Q-Bridge MIB (RFC2674) – RMON MIB (RFC2819) – RMON2 MIB (RFC2021) – Radius Accounting Client MIB (RFC2620) – Radius Authentication Client MIB (RFC2618) – Remote Ping, Traceroute MIB (RFC2925) – Support TP-Link private MIB
Gestión: – Aplicación Omada: Requerir el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller – Gestión Centralizada Controlador Omada Basado en la Nube Controlador de hardware Omada Controlador de software Omada – Acceso a la nube Sí. Requerir el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller – Aprovisionamiento sin contacto Sí. Requiere el uso del controlador basado en la nube Omada. – Funciones de gestión GUI basada en web Interfaz de línea de comando (CLI) a través de telnet SNMPv1/v2c/v3 Captura/información SNMP RMON (1,2,3,9 grupos) Plantilla SDM Cliente DHCP/BOOTP Imagen dual, configuración dual Monitoreo de CPU Diagnóstico de cables AEE SNTP Registro del sistema
Otros: – Certificaciones: CE, FCC, RoHS – Requisitos del sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux Contenido – SG2210XHP-M2 Switch – Power Adapter – Quick Installation Guide – Rubber Feet
Fecha de revisión: 07-11-2024 por RTY
